Beacon
Beacon uses BLE technology to transmit signals, serving as markers that continuously send specific identifiers to nearby devices at regular intervals.
Dolphin beacon devices are small wireless devices that use Bluetooth Low Energy (BLE) technology to transmit signals. These devices continuously transmit a radio signal at short, regular intervals. When the beacon device is in the desired range, the Gateway, equipped with Bluetooth, can detect its presence. The two Dolphin Beacon models are designed to save time and resources and increase profitability so that they can be installed according to the user's needs and at a low cost in all fleets.
Beacon ID DC50
Using this model of dolphin beacons to know the location of assets, the tracker or Gateway detects their presence in the desired areas. It sends the relevant information to the system. In this way, fleet managers can improve the management of various assets within specified limits.
Beacon Sensor DC50
This model of Dolphin Beacons provides users with more advanced features. Equipped with sensors, Beacon DC50 collects important data from assets, including temperature, humidity, and motion detection. This equipment helps managers to monitor specific indicators.
Features of Dolphin Connect Beacons
Long Battery Life
The devices' batteries will last for 3 to 5 years and then be replaceable to decrease costs.
Protocol Switch
The device can transfer data via three protocols including Eddystone, iBeacon, and Dolphin Custom Protocol.
Waterproof Cover
The strong & waterproof coating of both beacon models makes the device last longer.
Smart Design
The small size of the beacon devices makes them suitable for various applications in cars.
Easy Installation
Users can easily install the devices securely on the vehicles without destroying the wiring.
Technical Specifications
| Features | DC50-ID | DC50-Sensor |
|---|---|---|
| Functionality | ID Beacon | Sensor Beacon |
| Weight | 30 Gr | 30 Gr |
| Protocols | iBeacon, Eddystone | iBeacon, Eddystone |
| Battery Capacity | 550 mAh | 550 mAh |
| Replaceable Battery | Yes | Yes |
| Battery Life | 3-5 Years | 3-5 Years |
| Main Chip | Nordic NRF52 Series | Nordic NRF52 Series |
| Bluetooth Version | Compatible with Bluetooth 4.2 & 5.4 | Compatible with Bluetooth 4.2 & 5.4 |
| Bluetooth Signal Board | 50 Meters | 50 Meters |
| Protective Standard | IP67 | IP67 |
| Humidity Detection | - | From 0% to 100% |
| Operating Temperature | - | -20°C / + 60°C (-4°F / +140°F) |
| Storage Temperature | - | -20°C / + 70°C (No Battery) / 10°C / + 25°C (With Battery) |
Beacon Catalog
You can click the button below to download the Beacon Catalog:
